N-Type Jack to SMA Adapter 50 Ohm Straight Bulkhead IP67
N-Type to SMA Adapters, SMA to N-Type Adapters
AD-NJSMAP-2
$999.00
N-Type Jack to SMA Plug Adapter 50 Ohm Straight Bulkhead IP67
| Weight | 0.03904 kg |
|---|---|
| Manufacturer | Amphenol RF |
| Body Finish | Nickel |
| Body Material | Brass |
| Impedance (Ohms) | 50 |
| Insulator Material | PTFE |
| Panel Mounting Feature | Bulkhead |
| Operating Level | Commercial |
| Isolated | No |
| Low PIM | No |
| Temp (Max Degrees Celsius) | 165 |
| Temp (Min Degrees Celsius) | -65 |
| Non Magnetic | No |
| Adapter Side 1 Series | N-Type |
| Adapter Side 1 Style | Jack |
| Adapter Side 2 Series | SMA |
| Adapter Side 2 Style | Plug |
| Contact Finish | Gold |
| Contact Material | Beryllium Copper |
| Orientation | Straight |
